6. HYDRAULIC SYSTEM
6.1.2 REAR PUMP The rear pump is a gear pump which is driven by the PTO device of the transmission. It pick up oil from the oil tank and sends it to the control valve.
1. DRIVE GEAR 2. SNAP RING 3. FRONT COVER 4. OIL SEAL
5. VALVE BODY 6. SIDE PLATE 7. REAR COVER 8. DRIVEN GEAR
Fig. 6.2 Rear Pump
- 85 -
9. GASKET/BACK-UP STRIP 10. GASKET 11. BUSHING
