Monitoring System
Combined Transmission and Hydraulic Oil Filter (4) - This indicator illuminates when the transmission oil filter needs to be replaced.
Alert Indicators
Engine Air Filter (5) - This indicator illuminates when the engine air filter needs to be replaced.
Indicators
Illustration 127
g01002552
Engine Oil Pressure (1) -This indicator illuminates when the engine oil pressure is low.
Action Lamp (2) -This indicator will illuminate when a failure that is a warning category 2 or a higher warning occurs. If the lamp is illuminated, the machine needs to be serviced soon. The color of this indicator can be amber or red. An audible alarm may also sound when this indicator is illuminated. When a warning category 2 occurs, the action lamp flashes red and there is no audible alarm. In order to prevent severe damage to components, the operator is required to change the machine operation or the operator is required to perform maintenance to the machine. When a warning category 2S occurs, the action lamp flashes red and there is a constant audible alarm. In order to prevent severe damage to components, the operator is required to change the machine operation. When a warning category 3 occurs, the action lamp flashes red and there is an intermittent audible alarm. In order to prevent personal injury or severe damage to components, the operator is required to perform a safe engine shutdown. When the machine has been configured with no model designation, indicator (2) flashes amber and no audible alarm will sound. This condition will not log an error code. When the data link is not communicating with the display unit, indicator (2) flashes amber and no audible alarm will sound. This condition will log an error code. Battery Condition (3) - This indicator illuminates when the battery is not receiving a charge from the alternator.
Illustration 128
g01014331
Left Turn Signal (6) - This indicator flashes when the left turn signal is operating. Circle Steer (7) - This indicator is illuminated when circle steer mode is selected. Crab Steer (8) - This indicator is illuminated when crab steer mode is selected. Two-Wheel Steer (9) - This indicator is illuminated when two-wheel steer mode is selected. Engine Starting Aid (10) - This indicator is illuminated when the engine starting aid is switched on. Parking Brake Indicator (11) - This indicator illuminates when the parking brake is engaged. Right Turn Signal (12) - This indicator flashes when the right turn signal is operating.
