38 Product Information Section
Illustration 40
31200244
g01015547
This plate is located on the control group for the MSS. The control group is located in the engine compartment.
Illustration 43
g00937218
The following information is stamped on the plate: • "Model"___________________________________ • "Homologation number"______________________ • "PIN"____________________________________ • "Allowed total weight"________________________ • "Allowed front axle weight"____________________ • "Allowed rear axle weight" _____________________ • "Permissible towable mass"___________________ • "Unbraked towable mass"_____________________ • "Independently-braked towable mass"___________ • "Inertia-braked towable mass"_________________
Illustration 41
g00995393
Consult your Caterpillar dealer with any questions that concern the operation of the MSS in a specific country.
Italian Roading Homologation
Illustration 42
g00937590
This plate is located on the right side of the machine behind the front tire.
• "Towable mass fitted with an assisted braking system (hydraulic or pneumatic)"_______________
