Bucyrus International, Inc. 495HD Electric Mining Shovel
TRUCK FRAME The truck frame is a stress relieved welded cellular box structure which utilizes impact resistant steel in the major load carrying members. The low temperature toughness of the steel assures adequate strength and durability across a wide range of temperatures frequently encountered in machine applications. A fabricated support structure welded integrally into the truck frame supports the center pintle hub area. The inner diameter of the hub is machined to accept the center pintle bushing. Truck frame surfaces which mate to crawler side frames and swing rack are shop machined to assure proper alignment and solid foundation.
Aug. 2006
1 - 17
Manual No. 10428
