Bucyrus International, Inc. 8750 Walking Dragline
WINDSHIELD WIPER
Windshield Wiper Assembly Operator’s Cab
The cab’s front window assembly is equipped with an electric powered wiper to assist with visibility in inclement weather. Its control is on the console next to the operator. The wiper control is located on the LEFT control console. The wiper motor and gear reducer mounts on the upper right hand corner on the inside of the window. Adjust the rod from the gear reducer to center the wiper blade on the window. Maintain pressure of the wiper on the glass with the adjusting nut on the spring rod located at the top of the wiper arm on the outside of the window.
