Bucyrus International, Inc. 8750 Walking Dragline
PRIMARY CONTROLLERS The 2 primary controllers for machine operation are the manually-operated joysticks (masterswitches) situated on each side of the operator’s seat. NONE OF THE MACHINE MOTION CONTROLS ARE OPERABLE UNTIL LINE EXCITATION HAS BEEN ACTIVATED AND ENGAGED, as is indicated by the green light in the excitation start pushbutton on the Operator Console. For emergency exits, there is a smaller door located on the right side of the cab, just behind the operator’s seat. This door can be opened from either inside or outside the cab, by pushing down on the handle.
Operator’s Seat and Controls
Feb. 2007
25
Manual No. 10348 - Rev. 2
