Method Of Operation
4:13 Remove the Pump assembly from the transmission and recover the O ring seal
4:14 Remove the 20 Screws securing the casing.
4:15 Using suitable lifting equipment remove the rear transmission case. Lever slots are provided to assist removal. Caution! The bearing Cups and shims may fall from the case during removal
4:16 The Transmission with the rear casing removed.
4:17 Lift and remove the Output shaft assembly.
4:18 Remove the Screw and Washer from the end of the Forward High / Third clutch shaft.
47
