ELECTRICAL / ELECTRONIC APPLICATION & INSTALLATION MANUAL
5.5.1 ECM Connector Endbell
An AMP 638092-1 (Caterpillar part number 126-1774) Connector Endbell is available to provide additional protection and controlled wire routing for the harness at the ECM. 5.5.2 Twisted Pair Wiring
Twisted pair wiring must be used for the SAE J1587 Data Link, SAE J1922 Data Link, and the vehicle speed signal wires. There should be a minimum of one twist per inch within the harness. All twisted pair wires should not be twisted within an inch of the connector to avoid seal stress. The speedometer and tachometer outputs should also use twisted pair wiring. SAE J1939 Data Link wiring should comply with SAE J1939/11 specifications. 5.6 Accelerator Pedal Position Sensor Connector 5.6.1 Accelerator Pedal Position Sensor with Three Terminal Deutsch Connector
The 176-1602 (32 inch [81 cm] harness) and 176-1604 (6 inch [15 cm] harness) Accelerator Pedal Position Sensors require a Deutsch DT06-3S-EP04 (Caterpillar part number 3E-3367) mating connector with a Deutsch W3S (Caterpillar part number 3E3368) connector plug wedge.
Three Terminal Deutsch DT Plug Connector
Wedge
Figure 20 - Three Terminal Accelerator Pedal Position Sensor Deutsch DT Connector 5.6.2 Accelerator Pedal Position Sensor (176-1602 and 176-1604) with Deutsch Three Terminal Connector Wire Gauge Size
The connections may be made with #16 or #18 AWG SAE J1128 type SXL, GXL or equivalent wire. 5.6.3 Accelerator Pedal Position Sensor (176-1602 and 176-1604) with Deutsch Three Terminal Connector Wire Insulation Size Range
Outside diameter insulation range is 2.24 mm to 3.81 mm (0.09 to 0.15 in). 5.6.4 Accelerator Pedal Position Sensor with Three Terminal Packard Electric Connector
The 176-1605 Accelerator Pedal Position Sensor (6 inch [15 cm] harness) requires a Packard Electric Division 12110293 (Caterpillar part number 124-5641) mating connector.
Figure 21 - Three Terminal Accelerator Pedal Position Sensor Packard Electric Connector
C-10, C-12, C-15 & C-16 Truck Engines
29
