OPERATING INSTRUCTIONS RH 30 F Operation Defrosting the front and rear windows
Misted or iced windows obstruct the operator's view of the hazard zone. The machine may be set in motion only after the windows are defrosted and when the operator has a clear view of the hazard zone.
Fig. 2-44:
Ü Open the outlets (Fig. 2-44:completely and turn them in the direction of the rear window. Ü Turn knob (94, Fig. 2-45:) to maximum heating performance. Ü Turn rotary switch (60, Fig. 2-46:) to step 3
Fig. 2-42:
Fig. 2-45:
Fig. 2-43:
Ü Start up the engine. Full heating performance is available only after the engine has reached its operating temperature. Ü Close the outlets under the driver's seat (Fig. 2-42:). Ü Open the outlets (Fig. 2-43:) completely and turn them in the direction of the front window. Fig. 2-46:
BA RH30F(3 659 030.00)-EN
2-43
