OPERATING INSTRUCTIONS RH 30 F Operation (Fig. 2-19:)
No.
Element
Function
1
Clock
2
Thermometer
Pump transfer gearbox temperature
Indicates the oil temperature in the pump transfer gearbox
3
Pressure gauge
Engine oil pressure
Indicates the oil pressure in the diesel engine lubricating system
4
Thermometer
Diesel engine temperature
Indicates the temperature of the cooling liquid
5
Warning lamp
PMS (PUMP MANAGING SYSTEM)
Lamp flashes: §
when the electrical system is on (engine stationary)
§
in the event of a fault (engine running) short-circuit, cable break or defective componenent (magnetic pick-up, termperature probe for load-sensing or proportional valve)
Symbol
Lamp is permanently lit § 6
Warning lamp
CELECT warning
when the programmed hydraulic oil temperature of 80°C is exceeded.
Lamp is lit up in the event of an HPI fault The lamp moreover indicates the fault code. Contact Terex Germany after-sales service or engine manufacturer (see switch (52).
7
Warning lamp
CELECT warning
Lamp is lit up in the event of an HPI fault The lamp moreover indicates the fault code. Shut off engine Stop working. Contact Terex Germany after-sales service or engine manufacturer (see switch (52).
8
Warning lamp
CELECT warning
Lamp is lit up (e. g.): § when the engine oil pressure is too low §
when the cooling water temperature is too high
Shut off engine
