OPERATING INSTRUCTIONS RH 120 E Inspection and servicing Replacing the grease drum " Detach lines (11, 12, 13 and 14 Fig. 3-103:). " Unscrew wing nuts (6). " Detach plate (5). " Remove cover (4) together with grease pump (2) from grease drum (1).
Fig. 3-103:
" Replace the empty grease drum by a full one. " Place cover (4) with grease pump (2) back onto the grease drum. " Fasten plate (5) with wing nuts (6) on grease drum (1). " Refit lines (11, 12, 13 and 14).
BA RH120E(3 664 480.00)-EN
3-83
