OPERATING INSTRUCTIONS Inspection and servicing Brake chamber - Changing oil
Breather filter
Draining off oil
" Unscrew breather filter (1 and 5, Fig. 3-89:) and clean in white spirit or parafin.
" Place a collecting recipient for used oil under the pre-chamber. Choose the required capacity in accordance with the "Refilling quantities - Oil" table. " Unscrew drain plug (7, Fig. 3-89:) and drain off the oil completely. Slackening breather filter (5) allows the oil to run out more readily. " Clean screw plug (7). " Screw screw plug (7) back in place.
Fig. 3-89:
Filling in oil " Unscrew screw plug (6). " Fill in oil through opening of breather filter (5) until it flows out of opening in plug (6). " Screw plug (6) and breather filter (5) back in place.
3-74
BA RH120E(3 664 480.00)-EN
