OPERATING INSTRUCTIONS RH 120 E Inspection and servicing Track roller, Support roller
Support roller fastening
Inspect all track and support rollers visually for leaks and free movement at regular intervals.
Check fastening screws (3, Fig. 3-89:) regularly for tightness
Track roller fastening
Tighten screws with a torque wrench to the prescribed tightening torque torque (see “Technical Handbook”).
Check fastening screws (4 Fig. 3-89:) regularly for tightness: " Tighten screws with a torque wrench to the prescribed tightening torque (see “Technical Handbook”).
Fig. 3-89:
BA RH120E(3 668 330.00)-EN
3-75
