104 Operation Section (D6T LGP (OEM)) Transportation Information
WEBM1000
Transportation Information
8. Install the tie-downs at several locations and block the tracks in the front and in the rear.
Shipping the Machine
9. Cover the opening for the engine exhaust. Rotation of the turbocharger without engine operation can result in damage to the turbocharger.
Investigate the travel route for overpass clearances. Make sure that there is adequate clearance for the machine that is being transported. This proceeding is especially true for machines that are equipped with a ROPS/FOPS structure, a cab, or a canopy. Remove ice, snow, or other slippery material from the loading dock and from the truck bed before loading. Removing ice, snow, or other slippery material will prevent the machine from slipping as you load the machine. Removing ice, snow, or other slippery material will prevent the machine from slipping in transit. NOTICE Obey all state and local laws governing the mass, width and length of a load. Observe all regulations governing wide loads. 140
Consult your Cat dealer for shipping instructions for your machine.
Lifting and Tying Down the Machine
m WARNING Improper lifting and improper tie-downs can allow the load to shift or fail and cause injury or damage. Use only properly rated cables and slings with lift and tie down points provided. Follow the instructions in Operation and Maintenance Manual, “Lifting and Tying Down the Machine” for the proper technique for securing the machine. Refer to Operation and Maintenance Manual, “Specifications” for specific weight information. 141
Illustration 140
1. Place blocks under the trailer wheels or under the rail car wheels before loading, as shown. 2. Lower all attachments to the floor of the transport machine. Move the transmission control lever to the NEUTRAL position. 3. Engage the parking brake switch. 4. Stop the engine by turning the engine start switch key to the OFF position. Remove the key.
Illustration 141
5. Engage the parking brake switch in order to lock the parking brake.
for example only.
6. Turn the battery disconnect switch to the OFF position. Remove the key.
NOTICE Improper lifting or tiedowns can allow load to shift and can cause injury and damage.
7. Lock the door and lock the access covers. Attach any vandalism protection.
An image of a Track-Type Tractor with an attached ripper is shown
