Inspection and servicing Electrical system, control cabinets The electrical system control cabinets are located in the cab module and in the motor compartment. The cabinets are described in the spare-parts list (electrical circuit diagram) together with the designation of the electrical components.
Breather filter In the control cabinets For the 6600 V power supply,
For the 400 V system,
For the 24 V system,
Fig. 3-17:
the air is drawn in and cleaned by a ventilator with filter.
Emptying the dust trap Press dust trap (14, Fig. 3-17:) and hold until the dust trap is empty.
Emptying the dust collector Loosen clips (11, Fig. 3-17:). Remove dust collector (12) and empty. Fig. 3-18:
Filter element, clean / replace Remove dust collector (12, Fig. 3-17:). Withdraw filter element (13, Fig. 3-18:). Replace or clean filter element (13). Refit dust collector (12, Fig. 3-17:).
