OPERATING INSTRUCTIONS RH 340 Operation EMERGENCY STOP pushbuttons The entire electrical system is switched off with the EMERGENCY STOP pushbuttons.
on the righthand side at the counterweight This latter one is operate with the rope (3, Fig. 2-24:)
In an emergency, press the EMERGENCY stop. The EMERGENCY STOP pushbuttons are located
in the control column in the driver's cab (31, Fig. 2-22:)
Fig. 2-24:
The electrical system of the excavator can be switched on after the EMERGENCY SHUTOFF buttons are activated, to do so: Pull the EMERGENCY SHUTOFF buttons out Fig. 2-22:
in the control cabinet (2, Fig. 2-23:)
Windscreen washer The reservoir of the windscreen washing system (1, Fig. 2-25:) is installed in the cab module. For the reservoir capacity refer to the "Refilling quantities - Other" table.
Fig. 2-23:
Fig. 2-25:
