OPERATING INSTRUCTIONS RH 340 Operation Ramp-type ladder (optional)
Lowering the folding ladder (from the upper carriage)
Raising resp. lowering the folding ladder (Fig. 2-9:).
Start engine. Push lever (1, Fig. 2-10:)on control valve (2) downwards to position “ II “. The folding ladder is lowered (Fig. 2-9:) The folding ladder can also be lowered when the engine is stopped.
Fig. 2-9:
Raising the folding ladder (from the upper carriage) Start engine. Pull lever (1, Fig. 2-10:) on control valve (2) upwards to position “ I “. The folding ladder is raised (Fig. 2-14:)
Fig. 2-11:
Lowering the folding ladder (from the bottom) Pull down rope (3, Fig. 2-12:). The folding ladder is lowered (Fig. 2-9:).
Fig. 2-10:
The upper carriage can only be swung when the folding ladder is raised completely (Fig. 2-14:).
BA RH340(3 720 350.01)-EN
Fig. 2-12:
2-13
