OPERATING INSTRUCTIONS RH 340 Inspection and servicing Changing the gearbox oil Draining off oil The gearbox oil is drained with the service station (Fig. 3-104:) through
express coupling (4) for the lefthand pump transfer gearbox
express coupling (5) for the righthand pump transfer gearbox
Fig. 3-105:
The gearbox oil can also be filled in with the service station (Fig. 3-104:) through
express coupling (4) for the lefthand pump transfer gearbox
Unscrew cap of express coupling and connect hose line of the service vehicle.
express coupling (5) for the righthand pump transfer gearbox
The hose line and its use are described in the "hose line for oil and cooling liquid change" section.
Unscrew cap of express coupling and connect hose line of the service vehicle.
Fig. 3-104:
Remove hose after the oil has been drawn off. The coupling closes automatically. Screw on protective cap.
The hose line and its use are described in the "hose line for oil and cooling liquid change" section. The oil level must reach the upper mark on dipstick (1,Fig. 3-105:). Remove hose after the oil has been filled in. The coupling closes automatically.
Filling in oil
Screw on protective cap.
Fill in oil through the bore in breather valve (2, Fig. 3-105:). The oil level must reach the upper mark on dipstick (1).
BA RH340(3 720 350.01)-EN
3-91
