OPERATING INSTRUCTIONS RH 340 Inspection and servicing Draining the oil off the engine oil reservoir (optional)
Unscrew cap of epress coupling and connect hose line of the service vehicle
Read and observe: "Inspection and servicing – Safety instructions".
Risk of scalding from hot engine oil. The engines oil reservoirs may also be hot. Wear protective gloves and firm working clothing. Collect escaping oil and discard without polluting the environment. Fig. 3-21:
Draining off the oil Bring engine oil to operating temperature.
The hose line and its use are described in the "hose line for oil and cooling liquid change" section.
Park the machine on a horizontal surface and secure engine oil reservoir
Remove the hose line. The express coupling closes automatically.
Shut off the engines.
Screw on protective cap.
Draw off engine oil with the service station (Fig. 3-21:through
After the engine oil has been drawn off: Replace the engine oil filter.
express coupling (6) for the lefthand engine oil reservoir
express coupling (7) for the righthand engine oil reservoir
3-44
BA RH340(3 720 350.01)-EN
