G - Controls
Sideshift lock control of the arm on the frame Sideshift control (5a / 5b) in distributors is directly integrated in the distributor and is equipped with piloted one-way valve. With control in “sideshift locked” position, the one-way valve prevents the opening of the 4 hydraulic vices that lock the sliding of the mobile frame along the sliding guides, ensuring the continuous clamping. The clamping pressure of the 4 vices is maintained constant, through the intervention of the maximum pressure valve available on the distributor. By rotating the lever (5) to “sideshift unlocked” position and activating any distributor lever, the system pressure activates the one-way valve opening (through piloting), allowing unlocking hydraulic vices.
50 - En
