Transmission - Powershift transmission external controls
16.
17.
Remove Torx bolts (1) and cover (2). Repeat the procedure on the opposite end cover (3).
RCPH11WHL203BBU
15
RCPH11WHL758BAU
16
RAPH11WEL0226AA
17
Remove wiring harness (1). Remove cylindrical bolts (3), securing plates and pressure controllers (2).
WK - solenoid valve (5 - speed) 18.
Mark installation position of connecting housing (4) towards valve block (5).
19.
Remove cylinder bolts (1) and lock-up clutch valve.
20.
Remove bolt neck (2) and discard O-rings.
21.
Remove Torx bolts (3), and the connecting housing.
84605841 14/05/2012
21.135 / 52
