Transmission - Powershift transmission internal components
6.
7.
Secure the idler gear (1) using a retaining ring (2).
RCPH11WHL046BBU
6
RCPH11WHL045BBU
7
RCPH11WHL072BBU
8
Place O-rings (1) and (2) into the piston grooves and oil them.
NOTE: Check the function of the drain valve (3). There must be no jamming of the ball.
8.
Place piston into the disk carrier.
NOTE: Observe installation position.
47388956 22/05/2012
21.155 / 16
