MAINTENANCE/ADJUSTMENT IMPORTANT: DO NOT turn the key switch to the OFF position if the machine is steered against either the right hand or left hand steering stop. The steering wheel may kick back. NOTE: The secondary pump/motor should not be run continuously for more than 20 seconds at a time without a 2 minute cool down. 6. Restart the engine to build up steering pressure. Confirm that the secondary steering lamp within the instrument cluster is illuminated and that the secondary and that the secondary steering pump / motor is running. The secondary steering pump / motor should stop after approximately 3 seconds and the secondary steering lamp should go OFF. 7. If steps 2 through 6 function properly, the secondary steering system is operating correctly. If not, repair the secondary steering system and then retest the system. 8. Start the engine and allow the batteries to recharge for a minimum of 10 minutes.
TRIM THIS EDGE
NOTE: The secondary steering system will only function as long as there is sufficient battery capacity.
PARKING BRAKE CHECK NOTE: Test the parking brake at a maximum of 250 hours. Before you operate the machine periodically test the parking brake functions.
RD98K316
1. To release the park brake, all the following are required:
A. Make sure that there is adequate service brake pressure. (Brake warning lamp is OFF)
212
