INSTRUMENTS/CONTROLS
LIFT ARM AND BUCKET CONTROL WITH ISO PATTERN PILOT CONTROLS 3
1
2
4
N
5
1. PILOT LIFT ARM AND BUCKET CONTROL LEVER
BS06N853
Lift Arm Raise And Lower Control:
Bucket Dump And Curl Control:
The lift arm is controlled by pushing or pulling the right pilot control lever on this configuration.
The bucket is controlled by pivoting the r ight pilot control lever inward o r outward.
1. Lift Arm Up:
4. Rollback: (Curl)
The lift arm will raise UP by pulling back on the Right Pilot Control Lever.
The bucket will rollback (curl) when the Right Pilot Control Lever is pivoted inward.
2. Lift Arm Down:
5. Dump:
The lift arm will lower DOWN when the lever is pushed forward.
Pivoting the lever up toward the outside of the cab will dump the bucket.
3. Float:
NOTE: There is no detent or float position on the bucket dump and curl circuit.
To place the lift arm in Float, push the control lever all the way forward until a slight jump is felt. The lever will remain in this position until pulled back and out of detent. (toward neutral) In this detented, FLOAT position, the lift arm will float over changing ground contour.
