LUBRICATION
LOWERING THE OPERATOR’S COMPARTMENT INTO THE OPERATING POSITION 1. Make sure all tools or other items have been removed from the interior of the chassis before the operator’s compartment is lowered.
1
BD01C171 BD04N097
TRIM THIS EDGE
2. Release the cab hold open latch by pushing the lever (1) forward.
4. Install and tighten the operator’s compar tment mounting bolts to torque of 180 to 320 Nm (130 to 235 pound-feet).
1
3 2 BD05A062
BD01C142
3. Gripping both front cab hand holds near the top, slowly lower the cab into operating position.
5. Raise the loader lift arms and remove the pin (2) from the loader lift arm support strut (1). Place the l o a d e r l i f t a r m i n t h e s t o ra g e position and install the pin (2). See Storing the Support Strut on page 110.
IMPORTANT: On pilot models use caution when closing ROPS to ensure the pilot control handles do not get caught on the ROPS seat plate.
6. Before operating the skid steer m a k e s u r e t h e o p e r a t o r ’s compartment is fully lowered and the mounting bolts are installed and tightened.
108
