Case 221E Series 3 Tier 3 Compact Wheel Loader Parts Catalog Manual 87659825 - PDF DOWNLOAD

Page 67

0.06.6

p1

ROCKER SHAFT

REF 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

FN

PART NUMBER 504221907 504250345 14328301 99454296 504221915 504221914 17281681 4699783 4338920 14328801 16586925 2852247 504163121 504177226 504273002

YR/SN

QTY 1 1 2 1 4 4 1 8 8 1 10 11 1 1 4

DESCRIPTION SPACER SHAFT PLUG, M12, Tapered SCREW ROCKER ARM ROCKER ARM O-RING, D. 13,9 mm SP=2,6 SCREW NUT PLUG, M22, Tapered SCREW, M8X50 SCREW, M8X30 GASKET GASKET PLUG, M12X1,5

221E SERIES 3

02/08
