OPERATING INSTRUCTIONS
B. Use a cable or sling to fasten the load to the end of the dipper at the bucket pivot pin.
1. Approved load fitting ring.
C. Lift the load with the backhoe so the load is one or two inches (25 to 50 mm) above the ground.
2. B o o m l o w e r i n g s p e e d c o n t r o l device. (ISO 8643)
D. Swing the load all the way to one side.
3. Audible or visible alarm device to warm the operator of loads in excess of those authorised.
E. Move the load away from the machine. Make sure you keep the load one or two inches (25 to 50 mm) above the ground.
4. Special load lifting chart.
F. Lower the load to the ground if (1) one of the stabilizers is raised above the ground or (2) there is any other indication that the stability of the machine is reduced.
See your CASE dealer. IMPORTANT: IMPORTANT: Read the backhoe manufacturers instructions, before doing any lifting operations. The backhoe is NOT a crane. For this reason, always be very careful when you lift a load with the backhoe. Read the precautions that follow before you begin.
5. Always move the load slowly. Do not move the load over persons.
TRIM THIS EDGE
It is important to remember that lifting operations with the backhoe attachment are subject to strict legislation. Your machine must be fitted with the following statutory safety equipment:
Alt= to hide template information Alt+ to display template information
Lifting with the Backhoe
1. Know and understand each signal from the signalman before you begin.
7. Remember, lower the load to the ground if (1) one of the stabilizers is raised above the ground or (2) there is any other indication that the stability of the machine is reduced.
2. Always know the location of all persons in your working area. 3. Attach a hand line to the load before you start. Make sure the person holding the hand line is away from the load. 4. Test the load before you begin your job: A. Move the machine close to the load.
73
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1997_02_06
6. When the load is raised, keep all persons away until the load is lowered fully on the ground.
