2000-13
STEP 8
STEP 12
BD07G158-01
Remove the two plugs, remove the hood front mounting bolts.
BD07H107-01
Disconnect the lower radiator hose.
STEP 13 STEP 9
1
2
BD07F128-01
Remove the two plugs, remove the hood rear mounting bolts.
STEP 10 Attach lifting equipment to the hood, remove the hood from the machine.
STEP 11 BS07H289-01
1. SPACER 2. FAN MOUNTING BOLTS (4)
Remove the fan and spacer from the engine.
STEP 14 Tilt the ROPS cab or canopy, see section 9008.
BD07H108-01
Remove the upper radiator hose. Bur 5-7720
Issued 10-07
Printed in U.S.A.
