1650K
83 Cleaning the suction filter and magnetic rod Tilt the cab and loosen nut 1 to remove mesh filter 4 and magnetic rod 5. Wash both of them with solvent. Clean the container inside.
Every 1000 hours work 22. ENGINE VALVES Valve clearance check (cold engine) Have the valve clearance checked by specialized personnel. The valve clearance adjustment must be performed with cold engine or, in any case, at a temperature lower than 60 °C (140 °F). Valve clearance - Intake .................................................... 0.25 mm - Exhaust ................................................. 0.50 mm
A
WARNING Do not use gasoline or any flammable fluid to clean parts. Use approved, non flammable, non toxic commercial solvents only. Wear safety glasses with side shields when using compressed air to clean parts, so as to reduce the danger of personal injuries caused by flying particles. Limit the pressure to 2 bar (29 p.s.i.), in accordance with local or national regulations. Reinstall the filter, the magnetic rod and the cover. Check and top-off the oil level after changing it.
1 2
B C
D150-2M112
A. Feeler gauge - B. Clearance adjustment screw C. Wrench 14 mm (0.55 in).
4
3 5 F
Lock the nut to a torque of 24 Nm (17.70 ft lbs) and recheck the valve clearance. 23. BEVEL GEAR - STEERING AND BRAKES Change oil and wash suction filter Oil draining Place a container with at least 65-70 lit (17 - 18 1/2 US Gal) capacity under the transmission housing. Remove plugs A and let the oil drain completely. Retighten the plugs after cleaning them properly.
1850-2M0134
F. Transmission/torque converter suction filter - 1. Nut 2. Cover - 3. Gasket - 4. Mesh filter - 5. Magnetic rod.
A
1850-2M0133
A. Steering and brakes oil draining plugs
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
