Set up and maintenance instructions Valid from serial number 364690AAOrder number 179574-040
T-code 497 Date 2000-06-01
C-code/Section P1 Version 001
Fitting the battery Check that the battery cables are correctly connected to the battery. WARNING! Risk of short-circuiting. An incorrectly connected battery can cause a short-circuit. The polarity must correspond. Compare the markings on the cables and the battery poles. C
A
C
A
The battery can be replaced from both sides and from above. Depending on which side you wish to dismantle the battery, the battery lock (A) is fitted as illustrated. Also fit the fixed part (B) on the opposite side. Shims (C) are also supplied with the truck. These are used to take up any play between the battery and battery compartment wall. Fit these if necessary as illustrated.
Start up The following points must be checked before the truck is used.
Position no. Inspection points
Action:
1
Hydraulic function
Check the function
2
Throttle
Check the function, forwards/backwards
3
Safety switch against collisions
Check the function
4
Horn
Check the function
5
Steering
Check the function
6
Gate switch
Check the function
7
Platform
Check the function (return to the top position)
8
Hydraulic system
Check the oil levels and check for oil leakage
9
Drive assembly
Check for noise and oil leakage
Service Manual P24
Approved by: Fredrik Wigh
3–3
