Electrical systems Valid from serial number 555494AAOrder number 208587-040
5
T-code 675 Date 2002-06-04
C-code/Section 5000 Version 001
Parameters
The following parameters can be changed. NOTE ! Truck handling. Modifying specific truck parameters will change the driving characteristics of the truck. Do not change any parameters without the necesarry know-how.
5.1 Parameters Parameter
Min
Max
Std
Description
ACC. DELAY
0
9
6
Determines the acceleration ramp
MAX SP BACK
0
9
7
Maximum speed, fork direction, adjustment
MAX SP FORW
0
9
7
Maximum speed, steer wheel direction, adjustment
INVERSION BRAKING
0
9
9
Determines the deceleration ramp when the direction switch is inverted during driving
RELEASE BRAKING
0
9
5
Determines the deceleration ramp when the travel request is released
DECELER DELAY
0
9
5
Determines the deceleration ramp according to the speed controller position
OFF
Resets the hour meter of the service counter.
CHECK UP DONE CHECK UP TYPE
0
3
0
Allows setting of the service counter
CHECK UP HOURS
0
9
2
Indicates the time when the next service visit is required
ACC.DELAY The higher the parameter value, the longer it takes for the truck to reach the maximum speed.
MAX SPEED BACK The maximum speed in the fork direction can be adjusted as a percentage of maximum speed. 0 = 100 % 9 = 62 %
Service Manual Minimover LW13
Approved by: L-G Andersson
39
