Trouble shooting
7.1
General notes
7.2
Please observe strictly the safety regulations in the corresponding section of these operating and maintenance instructions.
i Note
Malfunctions are frequently caused by incorrect operation of the machine or insufficient maintenance. Whenever a fault occurs you should therefore thoroughly read these instruction on correct operation and maintenance. If you cannot locate the cause of a fault or rectify it yourself by following the trouble shooting chart, you should contact our customer service department.
Starting with jump wires
Choose this type of starting if the starter battery is exhausted and the machine cannot be started manually with the safety crank handle. !
Caution
A wrong connection will cause severe damage in the electric system. The auxiliary battery must have the same voltage as the starter battery.
Fig. 84
68
l
Loosen the hood fastening screws (1) on both sides and remove the hood fastening screws (2) on both sides (Fig. 84).
l
Fold the hood back to open.
l
Remove the battery holder and take off the vibration damping mat.
l
Check insulation mats, brackets and screw connections, replace if necessary.
BOMAG
BPR 70/70 D
