STEERING LEVERS/FOOT PEDALS
A
Forward And Reverse Travel NOTE: The following procedures describe forward, reverse, right & left as though you were seated in the operator’s seat.
1
2
FORWARD
Put the blade so that it is at the front of the machine as you sit in the operator ’s seat. Slowly push both steering levers* forward for forward travel. Pull both steering levers backward for reverse travel. *There are also foot pedals to operate the steering levers in the same manner.
NEUTRAL
REVERSE
B
Right Pivot Turn (Forward)
P–00811
C
Left Pivot Turn (Forward)
When the blade is to the rear, operate the steering levers/foot pedals in the opposite direction to when the blade is in the front. • Move the steering levers/foot pedals slowly. Abrupt lever motion will cause the machine to jerk.
W–2138–0189
Turning B–10979 MC–02109
Right Turn Push the left steering lever forward to turn to the right [B] while traveling in a forward direction.
D
Pull the left steering lever backward to turnto the right [D] while traveling in a reverse direction.
Right Pivot Turn (Reverse)
E
Left Pivot Turn (Reverse)
Spin–Turn Right Push the left steering lever forward and pull the right steering lever backward [F].
Dealer Copy -- Not for Resale
• Check the blade location before traveling.
Left Turn Push the right steering lever forward to turn to the left [C] while traveling in a forward direction. B–10979 MC–02109 MC–2109
Pul the right steering lever backward to turn to the left [E] while traveling in a reverse direction. Spin–Turn Left Push the right steering lever forward and pull the left steering lever backward [G].
F
G
Counter–Rotation Turn (Right)
Counter–Rotation Turn (Left) B–10979
MC–02109
28 of 66
–11–
220 (S/N 508215001 & Above) Excavator Operation & Maintenance Manual
