AIR CLEANER SERVICE
A
Replacing Filter Element
1
It is important to change the air filter element only when the Air Cleaner Icon in the right panel is ON (Item 1) [A] and you hear three beeps from the alarm. Replace the inner filter every third time the outer filter is replaced or as indicated on page 51.
B–15552 B–15553
Press and hold the LIGHT Button (Item 1) [B] for two seconds.
B 2
PRESS FOR CODES
1
B–15551
Outer Filter
C
Remove the wing nut and remove the dust cover [C].
N–20600
Remove the wing nut and remove the outer filter element (Item 1) [D].
D
NOTE: Make sure all sealing surfaces are free of dirt and debris. Install a new outer element. Install the dust cover and the wing nut [C]. Check the air intake hose and the air cleaner housing for damage. Make sure all connections are tight.
1 N–20598
70 of 118
50
751 Bobcat Loader Operation & Maintenance Manual
Dealer Copy -- Not for Resale
If the filter element needs replacement, theCODE [01–17] (Air Filter Plugged) will show in the HOURMETER / CODE DISPLAY (Item 2) [B].
