A
INSTRUMENT PANEL (Cont’d)
542B STANDARD CAB
Three Piece
1
The instrument panel has the following items [A] or [B]:
5a
1. LIGHT SWITCH – Controls the work and travel lights (Optional – 542B Standard Cab) 2. KEY SWITCH – For starting and stopping the engine.
4 3
3. FUSE (ACCESSORIES) – To protect the electrical system from overload.
2
4. FUSE (IGNITION) – To protect the electrical system from overload.
8a
9a
5. HOURMETER – Records the total operating hours of the loader.
B–12625
A
542B DELUXE
6. FUEL GAUGE – Shows the amount of fuel in the fuel tank (542B Deluxe Cab).
5a 3
7. ENGINE TEMPERATURE GAUGE – Shows the engine coolant temperature (542B Deluxe Cab).
10
1
8. ENGINE WARNING LIGHT – Engine oil pressure is low. Stop the engine if the light comes “ON”.
7
a. 542B Standard Cab b. 542B Deluxe Cab
4 2
9. TRANSMISSION WARNING LIGHT – Low hydrostatic transmission charge pressure, hydraulic filter needs replacement or high fluid temperature. Stop the engine if the light comes “ON”. a. 542B Standard Cab b. 542B Deluxe Cab
7 8b 9b
Dealer Copy -- Not for Resale
a. 542B Standard Cab b. 542B Deluxe Cab
B–12526
10. VOLTMETER – Shows the condition of the battery and the rate of charge (542B Deluxe Cab).
