3–3 STEERING LEVERS 3–3.1 Removing Steering Levers
1. Stop the engine.
2. Raise the operator guard (See Paragraph 5–1.1, Page 5–1).
B–05210
Fig. 3–3 Removing Front Panel
B–05327
Fig. 3–4 Removing Side Shield
Dealer Copy -- Not for Resale
3. Remove the front panel (Fig. 3–3).
4. Remove the bolts and remove the side shields (Fig. 3–4) on both sides.
5. Remove the bolts from the steering lever shields (Fig. 3–5) on both sides. The shields can be removed with the steering levers.
B–05328
Fig. 3–5 Removing Steering LeverShield
B–05329
Fig. 3–6 Disconnect Auxiliary Linkage
6. Disconnect the steering linkage at the steering levers (Fig. 3–7).
7. Disconnect the steering linkage at the steering levers (Fig. 3–7).
8. Remove the bolts at the pivot bearings (Fig. 3–8) both sides of the steering levers.
73 of 256
B–05330
Fig. 3–7 Disconnect Steering Linkage –3–3–
B–05331
Fig. 3–8 Removing Pivot Bearings 540, 543 Loader Service Manual
