STARTING THE ENGINE (Cont’d)
A
Do not use ether with glow plug (preheat) systems. Explosion can result which can cause injury or death.
1
W–2071–1285
P–26727 P–26728
Cold Temperature Starting See Normal Starting Page 15. Turn the key switch to the RUN POSITION.
B
Push the preheat button (Item 1) [A] on the left side of the instrument panel to preheat the glow plugs. Refer to the decal on the left side of the operator cab for operation of the preheat system [B].
Dealer Copy -- Not for Resale
Follow the steps under Normal Starting and repeat the preheating procedure until the engine starts. If the temperature is below 32 oF (0oC), use the following procedure to make starting the engine easier: •
Replace the engine oil with the correct type and viscosity for the anticipated starting temperature.(See Oil Chart Page 42.)
•
Make sure the battery is fully charged.
•
Install engine heater.
6708105
Warming The Hydraulic/Hydrostatic System Let the engine run for a minimum of 5 minutes to warm the engine and hydrostatic transmission fluid before operating the loader. If the warning light comes ON when operating the loader (cold), more warm up time is needed. STOPPING THE ENGINE Pull the engine speed control fully backward to decrease the engine RPM. Turn the key switch to the OFF position.
37 of 98
17
463 Bobcat Loader Operation & Maintenance Manual
