Generator and generating equipment
Preparation Remove starter motor Detach gearbox/clutch cover assembly Remove clutch Remove flywheel Rotor Removal Extract spring clip A from flywheel magnet by inserting snip-nosed pliers into cut-outs provided
-
Generating Equipment Removal Disconnect leads from temperature sensor and remove stator cable plug C from socket on equipment carrier Remove bolts D (13 & 19 mm), noting position of spacers, washers and injector pipe clip (if fitted) and remove carrier and equipment complete from engine.
Pull magnet B from flywheel with even movement, if necessary with suitable puller
Stator Removal Detach plug E from stator cables with fine implement, first marking their positions.
35
