T
Dolby® Digital Live and DTS Neo: PC support
T
Sound Blaster ProTM and MS Sound compatible
T
Built-in microphone
Storage subsystem T
Two 80/100/120/160/200 GB Serial ATA hard disk drives, supporting software RAID 0/1
T
Optical drive options: DVD-Super Multi double-layer drive (slot-load)
T
5-in-1 card reader, supporting Secure Digital (SD), MultiMediaCard (MMC), Memory Stick® (MS), Memory Stick PROTM (MS PRO), xD-Picture CardTM (xD)
Input devices T
88/89-key Acer FineTouchTM keyboard with 5-degree curve
T
Touchpad with 4-way scroll button
T
Four easy-launch buttons
T
Two front-access switches: WLAN LED and Bluetooth® LED-switches
Communication T
Acer Video Conference, featuring Voice and Video over Internet Protocol (VVoIP) support via Acer OrbiCamTM and optional Acer Bluetooth® VoIP phone
T
Acer OrbiCamTM 0.3 megapixel CMOS camera, featuring: t
30 degree ergonomic rotation
t
Acer VisageOnTM technology
t
Acer PrimaLiteTM technology
T
Modem: 56K ITU V.92 modem with PTT approval; wake-on ring ready
T
LAN: gigabit Ethernet; wake-on-LAN ready
T
WPAN: Bluetooth® 2.0+EDR (Enhanced Data Rate)
T
WLAN: Intel® PRO/Wireless 4965ABGN network connection (dual-band tri-mode 802.11a/b/g/n) Wi-Fi® CERTIFIEDTM solution, supporting Acer SignalUpTM wireless technology
I/O Ports
2
T
PCI Express Card slot (54mm type)
T
5-in-1 card reader (SD/MMC/MS/MS PRO/xD)
T
Four USB 2.0 ports
T
IEEE 1394 port
T
Microsoft MCE infrared (MIR) port
T
External display (VGA) port
T
DVI-D port (for selected models)
T
S-video/TV-out (NTSC/PAL) port
T
RF-in port (for selected models)
T
AV-in port
T
Headphones port with S/PDIF support
T
Microphone-in jack
T
Line-in jack
T
Ethernet (RJ-45) port
T
Modem (RJ-11) port
T
DC-in jack for AC adapter Chapter 1
