4.
Remove the two screws (D) securing the hard disk to the bracket and remove the hard disk from the bracket.
Step 1~2
Size (Quantity) M3 x L3 (2)
Color Black
Torque 3.0 kgf-cm
Removing the SSD Module
48
1.
See “Removing the Battery Pack” on page 44.
2.
See “Removing the Lower Cover” on page 45.
3.
Using the plastic tab, slide the SSD module away from the connector and lift to remove it from the system.
Chapter 3
