Removing the Switch Cover CAUTION: Using tools to remove the Switch Cover may cause damage to the outer casing. It is recommended that only fingers are used to remove the Switch Cover. 1.
See “Removing the Battery Pack” on page 50.
2.
Locate and remove the three securing screws as shown.
Step Switch Cover
Size M2.5*4
Quantity
Screw Type
3
3.
Turn the computer over and open the LCD module fully to expose the Switch Cover.
4.
Lift the Switch Cover as shown, leftside first.
5.
Lift the Switch Cover clear of the chassis.
Chapter 3
63
