Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
PhoenixBIOS Setup Utility Advanced Security Boot Power
Boot priority order: 1: IDE 4 : Toshiba MK1646GSX - (S1) 2: IDE CD : 3: PCI BEV : MBA v11.0.6 Slot 0800 4: USB HDD : 5: USB FDC : 6: USB KEY : 7: USB CDROM : 8: Excluded from boot order:
F1 Help ESC Exit
38
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter SelectXSub-Menu
Exit Item Specific Help Keys used to view or configure devices: Up and Down arrows select a device. <F5> and <F6> moves the device up or down. <f> and <r> specfies the device fixed or removable. <x> exculde or include the device to boot. <Shift + 1> enables or disables a device. <1 - 4> Loads default boot sequence.
F9 Setup Defaults F10 Save and Exit
Chapter 2
