Advanced The Advanced screen allows the user to configure the various advanced BIOS options. IMPORTANT:Making incorrect settings to items on these pages may cause the system to malfunction. Unless you have experience adjusting these items, we recommend that you leave these settings at the default values. If making settings to items on these pages causes your system to malfunction or prevents the system from booting, open BIOS and choose Load Optimal Defaults in the Exit menu to boot up normally.
Information
Main
PhoenixBIOS Setup Utility Advanced Security Boot Power
XUSB Self-Healing Secured Setup Configurations: Reset Configuration Data: LPC Port 80: PCI Hot-Plug Resources: I/O: Memory: Pre-fetchable Memory: Enable Multimedia Timer: Watchdog Timer:
[No] [No] [Enabled] [Enabled] [256] [2M] [2M] [Yes] [Disabled]
XHammer Configuration XIntegrated Devices XPnP Configuration XIDE Configuration XiGPU - Chipset LCD Panel type:
[EDID compliant]
F1 Help ESC Exit
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSub-Menu
Exit Item Specific Help Use this feature to tune USB timing event for USB devices
F9 Setup Defaults F10 Save and Exit
The table below describes the items, menus, and submenus in this screen. Settings in boldface are the default and suggested parameter settings. Parameter USB Self-Healing
Description Enter the USB Self-Healing menu.
Submenu Items •
Self-Healing
XOCHI Self-Healing XEHCI Self-Healing
32
Secured Setup Configuration
Prevents Plug and Play devices from changing system settings.
N/A
Reset Configuration Data
Clear the Extended System Configuration Data (ESCD) area using this option.
N/A
LPC Port 80
Enable or Disable LPC Port 80.
N/A
PCI Hot-Plug Resources
Enable or Disable Hot-Plug support.
N/A
I/O
Set the amount of I/O (in bytes) available to the Hot-Plug slots.
N/A
Memory
Set the amount of Memory (in bytes) available to Hot-Plug slots.
N/A
Pre-fetchable Memory
Set the amount of Pre-fetchable Memory (in bytes) available to the Hot-Plug slots.
N/A
Chapter 2
