Hardware Specifications and Configurations Processor Item
Specification
CPU type
AMD CPU S1g2 Processor (Griffin Series - Turion / Sempron); HT3 (1.2~2.6GT/s) (Bandwidth: 9.6GB/S to 20.8GB/s) 1.8GHz ~ 2.3GHz CPU Integrated 64bit or 128-bit DDR2 SDRAM controller One HyperTransport™ link to I/O devices One link, 16 bits in each direction, supporting speeds up to 800MHz (1.2GT/s) or 2.6Gigabytes/s in each direction L2 Cache 256Kb, 512Kb, or 1Mbytes The processor bus interfaces—HyperTransport 3 technology link and DDR2 memory—are both source-synchronous Supports up to 2 unbuffered SO-DIMMs 128-bit DDR2 SDRAM controller operating at up to 333MHz
Core logic
nVidia MCP77MH (North Bridge + South Bridge)
CPU package
638-Pin Lidless Micro PGA package (35mm x 35mm)
CPU core voltage
VCC_CORE0(based on CPU) VCC_CORE1(based on CPU) CPU)VDDNB(based on CPU) VLDT 1.2V_HT VDD i/O 1.8VSUS CPU Memory Interface SMDDR_VTEM(0.9V)
CPU Fan True Value Table DTS (degree C°)
Active Fan Speed (rpm)
56-64
2900
65-74
3300
75-84
3700
>85
4000
BIOS Item
Specification
BIOS vendor
Phoenix
BIOS Version
V1.3333
BIOS ROM type
W25X80VSSIG
BIOS ROM size
1Mbyte (8Mbit)
BIOS package
8-pin SOIC
Supported protocols
SPI
BIOS password control
Set by setup manual
Cache Item
18
Specification
Cache controller
Non
Cache size
256Kb, 512kb, or 1Mbytes
Chapter 1
