Replacing the Keyboard 1. Turn the keyboard over to expose the FFC, and use the pull-tab to insert the FFC into the connector.
2. Close the locking latch to secure the FFC in place.
3. Turn the keyboard over, taking care not to detach the FFC from the Mainboard.
4. Insert the keyboard by sliding the keyboard tabs in place first as shown
5. Rotate the keyboard downward and rest it in place.
