Removing the LCD Brackets and FPC Cable 1.
See “Removing the LCD Panel” on page 90.
2.
Turn the LCD panel over to expose the rear. Lift up the adhesive pads and detach the cables.
3.
Remove the four securing screws (two on each side) from the LCD Panel brackets.
Step LCD Panel
4.
Size M2*3
Quantity
Screw Type
4
Remove the LCD brackets by pulling away from the LCD Panel as shown.
Chapter 3
91
