Aspire 3810T/3810TG/3810TZ/3810TZG Exploded Diagram
80
ITEM
PART NO
DESCRIPTION
Q’TY
1
1310A2264501
ASSEMBLY,MODULE,MAIN
1
2
1397B0058001
ASSEMBLY,MODULE,USB
1
3
1397B0056101
ASSEMBLY,MODULE,CARD READER
1
4
1397B0056601
ASSEMBLY,MODULE,AUDIO
1
5
1397B0056301
ASSEMBLY,MODULE,VGA
1
6
1510B0696701
ASSEMBLY,CASE,TOP
1
7
1510B0697901
ASSEMBLY,CASE,BOTTOM,OFFLINE
1
8
1510B0698101
ASSEMBLY,COVER,HDD,OFFLINE
1
9
1510B0698001
ASSEMBLY,COVER,MEMORY,OFFLINE
1
10
1510B0722101
ASSEMBLY,BRACKET,FAN,OFFLINE
1
