Page 9

Chapter 1

System Specifications Features Below is a brief summary of the computer’s many feature:

Platform and memroy T

Intel® Celeron® M Processor 410/420/430 (1MB L2 cache, 1.46/1.60/1.73 GHz, 533 MHz FSB) or higher

T

ATI RC410ME+ATI SB460

T

Up to 2 GB of DDR2 533/677 MHz system memory, upgradeable to 2 GB using two soDIMM modules

Display and graphics T

T

14.1” WXGA Acer CrystalBriteTM TFT LCD, 1280 x 800 pixel resolution, supporting simultaneous multi-window viewing via AcerAcer DridVistaTM ATI Radeon® Xpress 200M chipset with integrated 3D graphics, featuring HyperMemory and up to 128 MB of shared system memory

T

16.7 million colors

T

Simultaneous LCD and CRT display, with LCD panel refresh rate at 70 Hz

T

MPEG-2/DVD hardware-assisted capability

Storage subsystem T

40/60/80/100/120 GB ATA/100 hard disk drive

T

Optical drive options: tDVD-Super tDVD-Dual

Multi double-layer

double-layer

tDVD/CD-RW

combo drive

Input devices T

88/89-key Acer FineTouchTM keyboard with inverted “T” cursor layout, 2.5 mm (minimum) key travel

T

Touchpad with 4-way scroll button

T

12 function keys, four media keys (play/pause, stop, previous, next), four cursor keys, two Windows® keys, hotkey controls, embedded numeric keypad, international language support

T

Four easy-launch buttons: Empowering Key, Internet, email, user-programmable button

T

Two front-access switches: WLAN,Bluetooth®

T

Audio system with two built-in 1W speakers and microphone

T

Intel® High-Definition audio support

T

Sound Blaster ProTM and MS-Sound compatible

Audio

Communication T

Chapter 1

Acer Video Conference featuring Voice and Video over Internet Protocol (VVoIP) support via Acer OrbiCamTM and optional Acer Bluetooth VoIP phone

1
