Disassembling the LCD Module (with video camera) 1.
Remove the four screw caps as shown.
2.
Remove the four screws holding the LCD bezel.
3.
Then detach the LCD bezel from the LCD module.
4.
Remove the two screws fastening the LCD inverter.
5.
Take out the LCD inverter from the LCD cover, then disconnect the LCD cable from the inverter.
6.
Remove the two screws holding the digital camera to the LCD panel.
7.
Detach the CCD panel from the CCD bezel assembly.
8.
Disconnect digital camera to LCD cable as shown.
9.
Remove the two screws fastening the CCD.
10. Take out the CCD from the CCD bezel. 11. Then remove the CCD hinge from the CCD bezel. 12. Slide the CCD latch to the right to remove the CCD latch. NOTE: The edges of the CCD latch is very fragile, please practice this step very carefully.
