Bottom View NOTE: This is engineering sample. The image above may not be exactly the same as the real main board you get.
1
U53
CPU socket
13
MINI1
Wireless LAN Card Slot
2
U51
North bridge ATI RC410ME
14
DM1
DIMM Slot1
3
U57
South bridge ATI SB460
15
DM2
DIMM Slot2
Audio Codec ALC883
16
HDD1
HDD connector
4 5
U49
BIOS ROM MX29LV800
17
LIN1
Line-in Jack
6
USB3
USB connector
18
MIC2
Headphones/Speakers/Line-Out Jack
7~8
USB1
USB connectors
19
LOUT1
Line-in Jack
9
CRT1
External VGA display
20
RTC1
RTC battery
10
MDC1
Modem board connector
21
FAN1
System fan connector
11
TRING1
Modem board cable connector
22
RJ1
RJ11 and RJ45 ports
12
CDROM1
ODD connector
23
BAT1
System battery module connector
Chapter 1
5
